Division VIII Chemical Nomenclature and Structure Representation Division
P-14.4 (b) lines 2/3. [corrected 28 May 2024]
For ....accommodate a substituent suffix in accordance with structural feature (d)
read ....accommodate a substituent suffix in accordance with structural feature (c)
P-16.2.4.1 (b) example 2. [corrected 9 October 2024]
For
N1-(2-aminoethyl)-N1,N2,N2 -trimethylethane-1,2-diamine
read N1-(2-aminoethyl)-N1,N2,N2-trimethylethane-1,2-diamine
P-16.7.1 (a), line 2.[corrected 30 March 2024]
For ...when followed by a suffix or 'en' ending beginning with 'a', 'e'....
read ...when followed by a suffix or ending beginning with 'a', 'e'....
P-22.2.4, example 4. [corrected 9 October 2024]
For 2H-1,4,8,11-oxatriazacyclotetradecine
1-oxa-4,8,11-triazacyclotetradeca-3,5,7,9,11,13- hexaene (PIN)
read 2H-1,4,8,11-oxatriazacyclotetradecine
1-oxa-4,8,11-triazacyclotetradeca-3,5,7,9,11,13-hexaene (PIN)
P-31.1.1.1, after text. [corrected 4 September 2024]
Add If the stereochemistry of a double bond is indicated in a structure it should be specified by E or Z with the appropriate locant. This includes double bonds in rings of eight or more members (see P-91.2.2).
P-31.1.3.1, example 4. [corrected 4 September 2024]
For cyclododeca-1,5-diene (PIN)
read (1Z,5E)-cyclododeca-1,5-diene (PIN)
P-31.1.3.1, example 5. [corrected 4 September 2024]
Replace the structure with:
for cyclopentadec-1-en-4-yne (PIN)
read (1Z)-cyclopentadec-1-en-4-yne (PIN)
P-31.1.3.2, example 1. [corrected 4 September 2024]
For1,4,7,10-tetraoxacyclododec-2-ene (PIN)
read (2Z)-1,4,7,10-tetraoxacyclododec-2-ene (PIN)
P-31.1.3.2, example 2. [corrected 4 September 2024]
For 1-oxa-4-azacyclododec-3-ene (PIN)
read (3E)-1-oxa-4-azacyclododec-3-ene (PIN)
P-31.1.3.2, example 3. [corrected 4 September 2024]
For 1,11-disilacycloicosa-5,7-dien-3-yne (PIN)
read (5Z,7E)-1,11-disilacycloicosa-5,7-dien-3-yne (PIN)
P-31.1.3.2, example 4. [corrected 4 September 2024]
For 1,10-disilacycloicosa-12,14,16-trien-18-yne (PIN)
read (12Z,14E,16Z)-1,10-disilacycloicosa-12,14,16-trien-18-yne (PIN)
P-31.1.4.3. [corrected 4 September 2024]
The order of the three criteria changed to make minimum number of compound locants first.
P-31.1.4.3 (2) formerly (1), example. [corrected 4 September 2024]
For bicyclo[14.3.1]icosa-11,13,18-trien-2-yne (PIN)
read (11E,13E)-bicyclo[14.3.1]icosa-11,13,18-trien-2-yne (PIN)
P-31.1.4.3 (3) formerly (2), example. [corrected 4 September 2024]
For bicyclo[11.3.1]heptadeca-2-en-11-yne (PIN)
read (2Z)-bicyclo[11.3.1]heptadeca-2-en-11-yne (PIN)
P-31.1.4.3 (1) formerly (3), example. [corrected 4 September 2024]
For bicyclo[8.3.1]tetradeca-4,6,10-trien-2-yne (PIN)
read (4Z,6E)-bicyclo[8.3.1]tetradeca-4,6,10-trien-2-yne (PIN)
P-31.1.5.1.2 (1), example. [corrected 4 September 2024]
For spiro[4.10]pentadec-10-en-8-yne (PIN)
read (10Z)-spiro[4.10]pentadec-10-en-8-yne (PIN)
P-31.1.5.1.2 (2), example. [corrected 4 September 2024]
For spiro[4.10]pentadec-6-en-14-yne (PIN)
read (6E)-spiro[4.10]pentadec-6-en-14-yne (PIN)
P-31.1.6.1, before examples. [corrected 4 September 2024]
Add If there is a choice the criteria of P-31.1.4.3 are applied.
P-31.1.6.1, example 1. [corrected 4 September 2024]
Replace the structure with:
For 1(1,3)-benzena-9(1,3)-cyclohexanacyclohexadecaphane-91(96),94-diene (PIN)
read not 1(1,3)-benzena-9(1,3)-cyclohexanacyclohexadecaphane-91(96),94-diene
add 1(1,3)-benzena-9(1,3)-cyclohexanacyclohexadecaphane-93,95-diene (PIN)
P-31.1.6.2, example 1. [corrected 4 September 2024]
For 1,7(1,3)dibenzenacyclotridecaphan-4-en-2-yne (PIN)
read (4Z)-1,7(1,3)dibenzenacyclotridecaphan-4-en-2-yne (PIN)
P-31.1.6.2, example 2. [corrected 4 September 2024]
For 1,7(1,3)dibenzenacyclotridecaphan-2-en-5-yne (PIN)
read (2E)-1,7(1,3)dibenzenacyclotridecaphan-2-en-5-yne (PIN)
P-31.1.7.2, example 3. [corrected 9 October 2024]
For [11,21:24,31-tercyclohexane]-11(21),22,32- triene (PIN)
read [11,21:24,31-tercyclohexane]-11(21),22,32-triene (PIN)
P-31.2.4.3, example left. [corrected 4 September 2024]
For 2,3,4,5-tetrahydroazocine (PIN)
read (6Z,8Z)-2,3,4,5-tetrahydroazocine (PIN)
P-44.4.1.2 (1), example left. [corrected 4 September 2024]
For cycloicosene (PIN)
read (E)-cycloicosene (PIN)
P-44.4.1.2 (2), example left. [corrected 4 September 2024]
For cycloicosa-1,8-diene (PIN)
read (1E,8E)-cycloicosa-1,8-diene (PIN)
P-44.4.1.2 (2), example right. [corrected 4 September 2024]
For cycloicos-1-en-3-yne (PIN)
read (1E)-cycloicos-1-en-3-yne (PIN)
P-44.4.1.10.1 (1), example left. [corrected 4 September 2024]
For cyclocosa-1,3-dien-5-yne (PIN)
read (1Z,3E)-cyclocosa-1,3-dien-5-yne (PIN)
P-44.4.1.10.1 (1), example right. [corrected 4 September 2024]
For cyclocosa-1,7-dien-3-yne (PIN)
read (1E,7Z)-cyclocosa-1,7-dien-3-yne (PIN)
P-44.4.1.10.1 (2), example left. [corrected 4 September 2024]
For cyclocosa-1,3-dien-5-yne (PIN)
read (1Z,3E)- (1Z,3E)-cyclocosa-1,3-dien-5-yne (PIN)
P-44.4.1.10.1 (2), example right. [corrected 4 September 2024]
For cyclocosa-1,5-dien-3-yne (PIN)
read (1E,5E)- cyclocosa-1,5-dien-3-yne (PIN)
P-46.1.12, example 1 right. [corrected 9 October 2024]
For [not 3-hydroxy-1-(1- hydroxyethyl)propyl
read [not 3-hydroxy-1-(1-hydroxyethyl)propyl
P-54.2, example 2. [corrected 4 September 2024]
P-64.2.2.3, example 8. [corrected 4 September 2024]
P-65.3.3.2.2.1 (2), lines 2/3. [corrected 28 May 2024]
P-65.6.3.3.2.2.1, example 1. [corrected 28 May 2024]
Page 809, P-65.6.3.3.2.2.1, example 3. [corrected 9 October 2024]
P-65.6.3.3.4.1, example. [corrected 28 May 2024]
P-69.2.4, example 2. [corrected 9 October 2024]
Page 1105, P-73.6, example 2. [corrected 9 October 2024]
P-93.5.5.1, example 2. [corrected 28 May 2024]
add (1M)-17-bromo-2,13-dioxabicyclo[12.2.2]octadeca-1(16),14,17-triene-15-carboxylic acid (PIN)
P-93.5.5.3, lines 3/4. [corrected 4 September 2024]
P-93.5.5.3, example 2. [corrected 4 September 2024]
Appendix 2, heptanylidene*. [corrected 9 October 2024]
Appendix 2. [corrected 9 October 2024]
Replace the structure with:
for cyclododeca-1,3,5,7,9-pentaen-11-yne (PIN)
read (1Z,3E,5Z,7E,9Z)-cyclododeca-1,3,5,7,9-pentaen-11-yne (PIN)
for 1,2-didehydro[12]annulene
read 1,2-didehydro[12]annulene (numbering shown)
For 1,3,6,8(2,5)-tetrafuranacyclododecaphan-11-en-2-one (PIN)
read (11Z)-1,4,7,10(2,5)-tetrafuranacyclododecaphan-11-en-2-one (PIN)
For ...representing the hydroxylic are exactly...
read ...representing the hydroxylic component are exactly...
For (2) 3,3′-oxydi(methyl benzoate)
read (2) 3,3′-oxybis(methyl benzoate)
For (2) butanedioylbis(oxy-2,1-phenylene) di(methyl butanedioate)
read (2) butanedioylbis(oxy-2,1-phenylene) bis(methyl butanedioate)
For ethane-1,2-diyl di(methyl butanedioate)
read ethane-1,2-diyl bis(methyl butanedioate)
For [(2,3,5,6-η) -bicyclo[2.2.1]hepta-2,5-diene]tricarbonyliron
read [(2,3,5,6-η)-bicyclo[2.2.1]hepta-2,5-diene]tricarbonyliron
For triaz-2-en-1-ium-1- yl (preselected prefix)
read triaz-2-en-1-ium-1-yl (preselected prefix)
For (14M)-15-bromo-2,13-dioxa-1(1,4)-benzenacyclotridecaphane-12-carboxylic acid (PIN)
read (14M)-15-bromo-2,13-dioxa-1(1,4)-benzenacyclotridecaphane-12-carboxylic acid
For ...present, all descriptors are must be cited (see P-91.2.2).
read ...present, all descriptors of double bonds in rings of more than seven nodes are cited (see P-91.2.2)
For (2E)-1(2,6)-pyridina-7(1,3)-benzenacyclododecaphan-2-ene (PIN)
read (2E)-11,14,15,16-tetrahydro-1(2,6)-pyridina-7(1,3)-benzenacyclododecaphan-2-ene (PIN)
For CH3-[CH2]5 -CH=
read CH3-[CH2]5-CH=
For 7- isoquinolyl
read 7-isoquinolyl
